Microwave motion sensor 8m MAX 2000W IP20 Thorgeon

Order product

Delivery time approximately 2 weeks

Product code :

White = 4751029890382

Black = 4751029893529

Specifications:

• Type: Motion sensor
• Sensor: High frequency
• Detection range: 360 degrees
• Maximum front reach: 8 meters
• Light intensity adjustment: Yes
• Installation method: Surface mounting
• Connection type: Screw terminals
• Color: White and Black
• Protection class: IP20
• Frequency: 50 - 60 Hz
• Shortest startup time: 10 seconds
• Daily usage time: 12 minutes
• Maximum switching power: 2000 W
• Maximum switching power LED: 1000 W
• Width: 115mm
• Height: 115mm
• Depth: 25 mm
• Rated voltage: 220 - 240 V

• Standard lighting control: Yes
• Optimal installation height: 2 - 6 meters
• Maximum lateral reach: 8 meters
• Maximum occupancy area: 4 square meters
• Sensitivity adjustment: Yes
• Suitable for ceiling mounting: Yes
• Material: Plastic
• Material quality: Thermoplastic
• Halogen-free: Yes
• Surface treatment: Untreated
• Surface finish: Matte
• Voltage type: AC
• Light intensity value: 3 - 2000 lux
• Temperature: -20 - +40°C
• Diameter: 115 mm
• Suitable for outdoor installation: No
• Suitable for indoor installation: Yes

Brochure white (in English)

Instructions for use white (in English)

Instructions for use black (in English)
