Microwave Motion Sensor 5-15m MAX 1200W IP20 Thorgeon

Order product

Delivery time approx. 2 weeks

Product code: 4751029894069

Technical specifications:

• Type: Motion sensor
• Sensor: High frequency
• Detection area: 360°
• Max range front: 15 m
• Mounting method: Flush mount (in tile)
• Color: White
• Protection class: IP20 (no protection against water or dust)
• Frequency: 50-60 Hz
• Shortest activation time: 10 s
• Daily operating time: 10 min
• Max switching power: 1200 W
• Max switching power LED: 300 W
• Width: 40 mm
• Height: 67 mm
• Depth: 25 mm
• Rated voltage: 220-240 V

• Optimal installation height: 1.5 - 3.5 m (wall) / 2 - 6 m (ceiling)
• Max range side: 15 m
• Material: Plastic (thermoplastic)

• Surface treatment: Untreated
• Surface finish: Matte
• Color code: RAL 9010 (silver gray)
• Voltage type: Alternating current (AC)
• Light intensity value: 3 - 2000 lux
• Temperature range: -20 - +40 °C
• Suitable for outdoor use: Yes
