10W, 800lm, LED Downlight, DIM, CCT, 40°, IP44, IK04, 3000K/4000K/5700K, 83-88mm, Nickel LED Downlight Thorgeon

Order product

Delivery time approx. 2-3 weeks

Product code: 4751029897350

Technical specifications:

• Light source: LED (non-replaceable)
• Voltage: 220-240 V
• Beam angle: Medium-wide beam (21-40°)
• Protection class: IP44 (protected against splashing water)
• Impact resistance: IK04 (small solid objects)
• Power: 10 W
• Color rendering index: CRI 90-100 (very good color rendering)
• Luminous flux: 800 lm (lumens)
• Luminous efficacy: 80 lm/W (good efficiency)
• Width: 96 mm
• Height/depth: 45 mm
• Length: 96 mm

Installation:

• Surface-mounted: No
• Recessed mounting: Yes
• Wall mounting: No
• Ceiling mounting: Yes

• Clamp mounting: No
• Low-voltage cable system: No

Adjustability:

• Swivel: Yes
• Motion sensor: No
• With light sensor: No

Housing:

• Color: Nickel
• Brushed surface: No

Electrical:

• Voltage type: AC
• Control gear type: LED control gear, voltage controlled
• Control gear included: Yes
• Replaceable control gear: Yes
• Dimmable according to control gear: Yes
• Dimming 0-10V: No
• Dimming 1-10V: No
• Dimming DALI-2: No
• Dimming DALI: No
• Dimming DMX: No
• Dimming DSI: No
• Dimming internal potentiometer: No
• Dimming GPRS: No
• Dimming LineSwitch: No
• Dimming manufacturer's proprietary system: No
• Dimming mains voltage modulation: No
• Dimming phase cut: Yes
• Dimming phase cut-on: Yes
• Programmable dimming: No
• Dimming RF: No
• Dimming Sine Wave Reduction: No
• Dimming Touch and Dim: No
• Dimming Zigbee: No
• Dimming with push-button: Yes

• No dimming function: No

Light distribution:

• Reflector: High-gloss
• Light diffuser: Diffuser lens/optics/panel
• Light distribution: Double asymmetrical

Energy efficiency:

• Average lifespan L70/B50 at 25 °C: 40000 h
• Average lifespan L80/B10 at 25 °C: 40000 h
• Luminous flux at average lifespan 35000 h, 25 °C (tq): 800 %
• Protection class: II

Lamp information:

• Lamp power: 10 W
• Light color: White
• Luminous flux: 800 lm
• Power factor: 0.8
• Flicker value Pst LM: 0.064
• Color temperature adjustable: No
• Luminous flux adjustable: No
• Beam angle adjustable: No
• Stroboscopic effect value SVM: 0.093

Dimensions:

• Outer diameter: 96 mm
• Recess width: 83 mm
• Recess height/depth: 41 mm
• Recess length: 83 mm
• Recess diameter: 83 mm

Additional information:

• Warranty: 5 years
• Luminaire with limited surface temperature, marked "D" according to EN 60598-2-24: No
• Internal emergency power supply: No
• Filament test according to IEC 60695-2-11: No
• Luminaire covering with thermal insulation material possible: No
• IFTTT support: No
• Color consistency (McAdam ellipse): SDCM6
• Compatible with Apple HomeKit: No
• Compatible with Google Assistant: No
• Compatible with Amazon Alexa: No


Brochure (English)
