Eaton IS-32/3 — 3-pole main switch/switch-disconnector, 32 A, 240 V AC

Product code: 276268
EAN: 4015082762681
Brand: Eaton

Product description

Eaton's IS-32/3 combines the features of a main switch and a switch-disconnector into one reliable device. It is designed for use in electrical panels and distribution boards where safe power isolation is required in all three phases. Its compact design, DIN rail mounting and high switching capacity make it an excellent choice for industry, buildings and service systems.

Features

• Voltage type: AC (alternating current)

• Number of poles: 3 (3-pole)

• Rated current: 32 A

• Rated voltage: 240 V AC

• Minimum rated voltage: 240 V

• Protection class: IP40

• Width in modules: 3 modules

• Installation depth (recess depth): 69.5 mm

• Breaking capacity (Icw): 2 kA

• Switching capacity: 12.5 kA

• Switch function: Main switch / isolating mode

• Indicator light: No

• Maximum lamp power: 0 W

• Number of NC contacts: 0

• Number of NO contacts: 3

• Number of changeover contacts: 0

• Forced separation (DIN VDE 0113): No

• Standards: IEC/EN 60947-3

Benefits and uses

• Allows simultaneous separation of all phases of current with a single device

• IP40 protection provides basic protection against dust and splashes

• With a compact 3-module width, you save space in central structures

• High short-circuit breaking capacity and compliance with standards ensure safety in special situations

• Compatible with accessories (e.g. additional switch contacts)

• Suitable for both industrial use and building electrical systems
