Eaton IS-25/1 – 1-pole main switch 25 A

Product code: 276262
EAN: 4015082762629
Brand: Eaton

Product description

Eaton IS-25/1 is a single-pole main switch/load disconnector with a rated load of 25 A. It is designed for DIN rail mounting in electrical cabinets and electrical systems where reliable main disconnection and safe isolation are required. The IS series meets the requirements of IEC/EN 60947-3.

Specifications

• Brand/Series: Eaton IS/Eaton Moeller

• Product code (MPN): 276262

• EAN / GTIN: 4015082762629

• Rated load current (In): 25 A

• Number of poles: 1 pole (1P)

• Voltage (rating): 240 V AC

• Breaking capacity: 2 kA

• Switching capacity: 12.5 kA (In = 16-80 A in class)

• Module width: 1 module / 1 module

• Depth / construction depth: ~ 69.5 mm

• Width/Dimensions: 17.5 mm width, height ~ 76 mm

• IP rating: IP40 (cover) / IP10 in some specifications
• Use category: AC-22 (variation of intended use)

• Connection cable cross-section: 2.5 – 50 mm²
• Operating temperature: –5 °C … +40 °C (operation and environment)

Features and benefits

• Allows main power to be disconnected with one pole

• Modular design — easily mountable on a DIN rail

• High breaking capacity (12.5 kA) ensures safety against short circuits

• Isolator function according to IEC/EN 60947-3 standard

• Only 1 module wide — saves space in the electrical panel

• Well suited for industrial and home installations as a main switch
